Custom Fused Silica Mirrors for High-Power Laser Applications

Avantier’s fused silica mirrors are engineered for demanding laser system applications, offering exceptional performance in terms of surface quality, thermal stability, and damage threshold. Designed for use with YAG lasers and other high-power systems, our silica mirrors are optimized for precision and durability.

A sample design of Fused Silica Mirrors

Substrate Material

Our optic mirrors are manufactured from Corning 7980 fused silica or equivalent high-purity, industrial-grade fused silica substrates. These materials are chosen for their ultra-low thermal expansion, high laser damage threshold, and excellent resistance to environmental stress. We also offer UV fused silica mirrors for enhanced transmission and reflectivity in ultraviolet wavelength ranges.

Dimensions & Tolerances

Diameter range

Ø 7 mm – 410 mm

Tolerance: Diameter

±0.254 mm

Tolerance: Thickness

±0.254 mm

Shapes and sizes

Custom available upon request

These mirrors can be engineered for specific angles of incidence, including standard configurations such as 45 degrees.

Surface Accuracy & Quality

Surface flatness

Standard λ/4 @ 633 nm; High-precision options up to λ/10 or λ/20

Surface quality

60/40 or laser-grade 10-5 scratch dig

Clear aperture

>90% of the diameter

Designed for minimal wavefront distortion, ideal for laser lines at 1064 nm and other critical wavelengths

Coating Design & Specifications

Our custom coated fused silica mirrors are available with a wide selection of metal and dielectric coatings. Each coating is engineered for specific laser system demands and optimized wavelength ranges. Coating Options:

Coating Type

Description

Wavelength Range

Aluminum (AlSiO)

Bare or protected, enhanced for visible/UV applications

UV to Visible

Gold

Bare or protected, with high IR reflectivity

Infrared

Silver

Protected silver, broadband performance

>400 nm

Dielectric

High-reflectivity, laser line coatings with high damage threshold

Narrowband or broadband (e.g., 320–450 nm, 750–1100 nm, 1064 nm)

Applications

  • Laser machining
  • Beam delivery systems
  • Scientific instrumentation
  • Medical lasers
  • Industrial optics.
Custom coating designs are available for applications such as beam steering, laser diagnostics, or multi-wavelength laser processing.

Why Choose Avantier’s Silica Mirrors?

  • Built with high-purity fused silica substrates
  • High surface accuracy and premium scratch dig specifications
  • Designed for use in YAG laser and high-power laser systems
  • Coatings engineered for durability at standard angles of incidence
  • Available in large formats with tight mechanical tolerances
  • Ideal for 1064 nm, 45-degree AOI, and multi-line laser systems
